1. High speed, Max speed is 40 pcs/min.
2. Easy operation, the min setting time of change model is 8 minutes.
3. Non't need to move cameras when change sizes everytime.
4. Double 10 million pixels Germany Basler cameras.
5. Dual feeding system, one button change box feeding to hardcover feeding system, no need to reset again.
6. Box detecting system.
Advantages:
Can connect with four sides wrapping machine to make the hardcover
Can work with box wrapping machine to make rigid box
Can make special box, such as slant side box (videos are available)
With 2 sets LS-F6 box forming machines, the speed of the whole line can reach around 13800 pcs/day
Only need 7 minutes when change product mode
One bottom to change case to box
No stop working when change different size, because one F6 for presetting and another one can keep working
Optional function:
- Glue Viscosity Device : Automatic detecting the hot melt glue thickness.
- Air Operated Double Diaphragm Pump: Applied in white glue pumping.
- Bottom sucker hardcover feeding device: Special design for feeding hardcover, to avoid scraping hardcover.
Specifications of LS-450plus:
| Type | LS-450plus |
| Paper size (Max) | L800*W600mm |
| Paper size (Min) | L135*W100mm |
| Max box size | L600*W400*H120mm |
| Min box size | L80*W65*H15mm |
| Book cover (Max) | L750*W450mm |
| Book cover (Min) | L150*W100mm |
| Paper thickness | 100-350g/㎡ |
| Paper stacking height | 280mm |
| Motor power / voltage | 7.5kw/380v, 3 phase |
| Heating power | 8kw/380v, 3 phase |
| Air supply | 10L/min 0.6Mpa |
| Working speed | 15-45 sheets/min |
| Machine dimension | L5980*W3180*H2100mm |
| Weight of machine | 2100kg |
